Double Sided Closed Cell Pvc Foam Tape

This double-sided PVC foam tape offers strong adhesion and excellent weather sealing. Its closed-cell structure prevents moisture absorption, making it ideal for insulation, gasketing, and cushioning in various applications. Durable and versatile.

Product Description

Dual Sided Closed Cell PVC Foam Tape: The Ultimate Sealing & Bonding Service

Double Sided PVC Foam Tape, your ultimate solution for structural glazing, securing, and industrial assembly. Engineered from high-density, shut cell PVC foam, this tape is made to deliver an unparalleled, durable bond and an impenetrable seal against the aspects. Coated on both sides with a high-strength acrylic adhesive, our closed cell PVC foam tape is the specialist’s choice for the most demanding applications.The core of the product is its high-performance shut cell PVC, which creates a durable framework that efficiently secures out water, air, dirt, and light. When you require integrity, you require a shut cell PVC tape that will not compress or weaken gradually.

TECHNICAL DATA

1 1

Any Material

1 3

Any Thickness

1 2

Any Width

1 5

Any Length

1 4

1 or 2-Sided

TOTAL THICKNESS
LENGTH
RELEASE FILM
FOAM
ADHESIVE
FLAMMABILITY
1.6MM-12.7MM (Customizable)
6,9,12,18MM (Custom roll lengths)
Blue release film
PVC Foam
Acrylic
UL94 HBF/HF-1/V-0, FMVSS 302
Foam Density
Shore 00 Hardness
Tensile Strength
Force to Compress
Elongation
180° Peel Strength
350±50kg/m³
80±10°
≥800kPa
≥50kPa
≥70%
0.82N/mm

Key Features:

Superior Sealing Performance:

The signature shut cell PVC foam structure creates an impermeable barrier. It is suitable for waterproof, dustproof, and sound insulation applications, ensuring the architectural stability of your window systems and settings up.

High-Strength Acrylic Adhesive:

Our double sided PVC foam tape includes an effective acrylic adhesive with remarkable shear toughness and high peel bond. It produces a protected, lasting bond to a wide array of surfaces including metal, plastic, timber, and silicone.

Enhanced for Structural Glazing:

Particularly designed for use in architectural spacer systems, the distinct shut cell PVC structure enables the correct healing of architectural silicones on all sides, an important attribute for drape wall surface and glazing installations.

Resilient and Sturdy performance:

It supplies excellent shock and resonance absorption, making it ideal for reducing NVH in vehicle applications and securing elements during transport. Its low thermal conductivity additionally enhances the energy effectiveness of your framework.

Typical Applications:

The convenience of our double sided pvc foam tape makes it the excellent option for a large range of demanding industries:

  • Glazing: Set up glass and produce an excellent seal in metal, timber, and vinyl sash systems.
  • Heating and cooling: Seal home heating and air flow air duct systems to enhance performance and stop leaks.
  • Acoustic engineering: Moisten sound and lower vibration in air handling units and various other tools.
  • Automotive: Reduce sound, vibration, and cruelty (nvh) inside cars.
  • General assembly: Usage for shop display cases, aquatic glazing, and die-cut gaskets.
  • Pick gmark shut cell pvc foam tape for a trusted, cost-effective, and high-performance remedy that safeguards your online reputation and makes certain consumer complete satisfaction.
FAQ

Popular Question

PVC foam tape is highly versatile and primarily used for sealing (against water, air, dust, light), gasketing, cushioning, vibration damping, and thermal/acoustic insulation. Common applications include window and door glazing, HVAC systems, automotive components, appliance manufacturing, and die-cut gaskets for various industrial equipment.

Our standard PVC foam tapes generally perform well in a temperature range of approximately -20°C to +80°C. For specific temperature requirements or extreme conditions, please consult with us as we may have specialized formulations or can guide you on suitability. (You'll need to insert your actual typical temperature range here)

The closed-cell structure is critical. It prevents the absorption of water, air, and dust, making it an excellent material for sealing and gasketing. It also contributes to the foam's good compression recovery, cushioning properties, and thermal/acoustic insulation capabilities.

 Many of our PVC foam tape formulations possess inherent flame-retardant properties. Specific grades can meet industry standards like UL 94 (e.g., HF-1, V-0). Please discuss your specific flame retardancy requirements with our technical team.

Yes. While our standard stock may include single-sided adhesive PVC foam tape, we can manufacture double-sided (double-coated) PVC foam tape by request to meet your specific bonding and assembly needs.

To provide an accurate quote, please share details about your application, required dimensions (thickness, width, length), density or firmness needed, adhesive requirements (single or double-sided), quantity, and any specific performance criteria (e.g., temperature resistance, flame retardancy, certifications).
